Product Overview
This professional high-performance mass loaded vinyl (MLV) is a 5kg/sq.m acoustic barrier mat, designed specifically to block unwanted noise in automotive applications. Its flexible composition allows it to conform easily to various surfaces, making it ideal for use in vehicles.
Key Features
- Acoustic barrier mat designed for effective noise reduction
- Flexible for automotive use, enabling easy installation
- Sheet/roll size: 1.25m x 1m
- Total coverage per roll: 1.25 sq.m / 13.4 sq.ft
- Thickness: 2mm
- Density: 5kg/sq.m
- Total roll weight: 6kg
- Temperature threshold: 95°C / 100°C short
- Significant reduction in sound transmission
Installation Notes
For optimal results, installation typically requires the use of Velcro, adhesive, or taped edges. The flexibility of the MLV allows it to be shaped to fit the contours of a vehicle's transmission tunnel, footwell, or door card.
Typical Uses
This product is suitable for various applications, including:
- Fitting to vehicle floors to prevent road noise from entering the cabin, often installed over sound-deadening mats
- Lining panels at home to minimise noise transfer
Technical Specifications
| Specification | Measurement |
|---|---|
| Sheet/Roll Size | 1.25m x 1m |
| Total Coverage | 1.25 sq.m / 13.4 sq.ft |
| Thickness | 2mm |
| Density | 5kg/sq.m |
| Total Roll Weight | 6kg |
| Temperature Threshold | 95°C / 100°C short |
Frequently Asked Questions
-
Can this mat be used in home applications?
Yes, it can be used to line panels at home to reduce noise transfer. -
What materials are compatible with this MLV?
It works well with closed-cell foam materials for enhanced sound absorption. -
Is professional installation recommended?
While it is easy to install, professional installation can ensure optimal performance.
£9.99 Flat UK Shipping
Dispatched within 1-2 working days
Quality Products
Carefully selected products
Expert Support
Call +44 1282 270214
Easy Returns
14-day returns, open and inspect first
| Product Type | MLV Mass Loaded Vinyl |
| SKU | D_SPS125 |
| Weight | Contact for details |
| Availability | ✓ In Stock |
Before You Start
- Clean the surface with isopropyl alcohol or degreaser
- Ensure the surface is completely dry
- Work at room temperature (15°C+) for best adhesion
- Have a roller and utility knife ready
Application Steps
- Step 1: Measure and cut the material to size
- Step 2: Peel back the release paper
- Step 3: Press firmly onto the clean surface
- Step 4: Use a roller to eliminate air bubbles and ensure full contact
- Step 5: For CLD mats, overlap edges slightly for complete coverage
Pro Tips
- For CLD mats: 60-80% coverage gives 95% of the benefit
- Focus on the centre of large flat panels
- Apply CLD first, then CCF/MLV, then acoustic foam
- Use a heat gun in cold conditions to improve adhesion
Shipping
- £9.99 flat-rate shipping on all UK orders
- Dispatched within 1-2 working days (order before 2pm, Mon-Fri)
- 3-6 working days tracked delivery
- Full tracking provided via email
Returns
- 14-day returns on any order, for any reason
- You can open and inspect before you decide
- Contact us before returning: sales@soundproofingshop.co.uk
- Refunds processed within 5 working days
For damaged or faulty items, contact us immediately — we'll arrange a free replacement or full refund.
Frequently Asked Questions
Everything you need to know about sound deadening
How much sound deadening material do I need?
Coverage depends on your vehicle and goals. For basic noise reduction, cover 25-40% of each panel. For maximum results (audio builds, full insulation), aim for 60-80% coverage. Our team can advise on exact quantities for your vehicle — just get in touch.
Can I install sound deadening myself?
Absolutely. All our products are designed for DIY installation with peel-and-stick application. You'll need basic tools — a roller, utility knife, and clean surface. Most door panels take 30-60 minutes. We include installation tips with every order.
What's the difference between CLD, CCF and MLV?
CLD (Constrained Layer Damping) mats reduce vibration and panel resonance — the foundation layer. CCF (Closed Cell Foam) blocks airborne noise and adds thermal insulation. MLV (Mass Loaded Vinyl) is a dense barrier that blocks sound transmission. For best results, use all three in layers.
Do you offer trade or bulk discounts?
Yes! We offer competitive pricing for trade customers, van conversion businesses, and bulk buyers. Contact us with your requirements for a custom quote. Bundle deals are also available on our website.
How fast is delivery?
Orders placed before 2pm are dispatched within 1-2 working days. Once dispatched, transit typically takes a further 2-4 working days. Total delivery time is usually 3-6 working days from when you place your order. Delivery is a flat £9.99 to any UK address. We ship nationwide across the UK.
Can I return products if they're not suitable?
Yes, we offer a 14-day return policy on any order, for any reason, and you may open and inspect it first. Please contact our team to arrange a return. Return postage is yours unless the item is faulty. Items cut to your specification are non-returnable unless faulty.
Need Help Choosing the Right Product?
Our sound deadening experts are here to help. Whether you're doing a full van build or a simple door upgrade, we'll recommend the perfect solution for your project.
