Product Overview
The Premium Thermal Acoustic Bonnet Liner is specifically designed for classic cars and high-performance vehicles. It effectively reduces engine noise and heat transmission through the bonnet, making it an essential component for diesel, turbocharged, or supercharged engines.
Features
- Reduces engine noise and heat through the bonnet
- Conforms easily to specific bonnet applications
- Self-adhesive for easy installation with a simple peel and stick application
- Withstands temperatures exceeding 100°C (maximum 110°C)
- Protects bonnet paint from harsh engine temperatures
- Designed to complement other sound deadening installations
- Provides noise reduction and thermal insulation properties
- Durable reinforced top layer material for tough environments
- Ideal for vehicle bonnet, firewall, and engine compartment use
- Fire Retardant (ISO 3795:1989 certified)
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Thickness | 10mm |
| Sheet Size | 100cm x 150cm |
| Area Coverage | 1.5 sq.m (1 sheet) |
Technical Specifications
- Material: High-quality thermo acoustic closed cell foam with a reinforced aluminium heat shield layer
- Fire Retardant: Complies with ISO 3795:1989
- Temperature Resistance: Up to 110°C
Frequently Asked Questions
Q: How do I install the bonnet liner?A: The liner is self-adhesive, allowing for a straightforward peel and stick application on the desired surface.
Q: Can this liner be used on all vehicle types?A: Yes, the large sheet size is designed to fit most vehicles, making it versatile for various applications.
Q: Is the liner effective in extreme temperatures?A: Yes, this liner is designed to withstand high temperatures and is effective in protecting the vehicle's paint and reducing noise.
Express Shipping
Same day dispatch before 2pm
Quality Guaranteed
Independently tested products
Expert Support
Call +44 1282 270214
Easy Returns
14-day returns on unused items
| Product Type | CCF Noise Barrier |
| SKU | D_SPS135 |
| Weight | Contact for details |
| Vendor | soundproofingshop.co.uk |
| Availability | ✓ In Stock |
Before You Start
- Clean the surface with isopropyl alcohol or degreaser
- Ensure the surface is completely dry
- Work at room temperature (15°C+) for best adhesion
- Have a roller and utility knife ready
Application Steps
- Step 1: Measure and cut the material to size
- Step 2: Peel back the release paper
- Step 3: Press firmly onto the clean surface
- Step 4: Use a roller to eliminate air bubbles and ensure full contact
- Step 5: For CLD mats, overlap edges slightly for complete coverage
Pro Tips
- For CLD mats: 60-80% coverage gives 95% of the benefit
- Focus on the centre of large flat panels
- Apply CLD first, then CCF/MLV, then acoustic foam
- Use a heat gun in cold conditions to improve adhesion
