Product Description
Introducing the Premium self-adhesive flexible foam liner, designed for exceptional vehicle heat and sound insulation when applied over sound deadening materials. This unique closed cell foam formulation provides superb thermal insulation and acoustic absorption in a 12mm (1/2") profile.
When installed in your vehicle, this foam liner acts as a thermal insulating layer, helping to stabilize cabin temperatures throughout the year.
This high-quality liner retains its shape under pressure while being flexible enough to trim easily in various areas of the vehicle. It is water-resistant, high-temperature resistant, and flame retardant, meeting vehicle safety standards.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Roll Size | 600cm x 50cm |
| Pack Coverage | 3sqm / 32.3sq.ft |
| Thickness | 12mm (1/2") |
| Temperature Range | -40°C to +100°C |
| Thermal Conductivity | 0.034 W/mK |
| Flammability Standard | ISO 3795:1989 |
Key Features
- Self-adhesive for easy installation
- Flexible closed cell nitrile elastomer material
- Resilient finish that absorbs, insulates, and isolates sound and heat
- Water and heat resistant
- Maintains shape under pressure
Typical Uses
- Fitting to vehicle panels to prevent road noise and help insulate the cabin.
- Lining panels, cupboards, and doors at home to insulate and prevent noise transfer.
Frequently Asked Questions
Q: Can this liner be used in high-temperature environments?A: Yes, the liner is designed to withstand temperatures from -40°C to +100°C.
Q: Is the liner easy to trim for installation?A: Yes, the liner is flexible and can be trimmed easily to fit various areas.
Q: Does this product meet safety standards for vehicle interiors?A: Yes, it is flame retardant and tested to meet ISO 3795:1989 standards.
Express Shipping
Same day dispatch before 2pm
Quality Guaranteed
Independently tested products
Expert Support
Call +44 1282 270214
Easy Returns
14-day returns on unused items
| Product Type | CCF Noise Barrier |
| SKU | D_SPS51 |
| Weight | Contact for details |
| Vendor | soundproofingshop.co.uk |
| Availability | ✓ In Stock |
Before You Start
- Clean the surface with isopropyl alcohol or degreaser
- Ensure the surface is completely dry
- Work at room temperature (15°C+) for best adhesion
- Have a roller and utility knife ready
Application Steps
- Step 1: Measure and cut the material to size
- Step 2: Peel back the release paper
- Step 3: Press firmly onto the clean surface
- Step 4: Use a roller to eliminate air bubbles and ensure full contact
- Step 5: For CLD mats, overlap edges slightly for complete coverage
Pro Tips
- For CLD mats: 60-80% coverage gives 95% of the benefit
- Focus on the centre of large flat panels
- Apply CLD first, then CCF/MLV, then acoustic foam
- Use a heat gun in cold conditions to improve adhesion
Shipping
- Express shipping on all UK orders
- Same day dispatch on orders placed before 2pm (Mon-Fri)
- 1-3 working days delivery via express courier
- Full tracking provided via email
Returns
- 14-day returns on unused, unopened products
- Products must be in original packaging
- Contact us before returning: sales@soundproofingshop.co.uk
- Refunds processed within 3-5 working days
For damaged or faulty items, contact us immediately — we'll arrange a free replacement or full refund.
Frequently Asked Questions
Everything you need to know about sound deadening
How much sound deadening material do I need?
Can I install sound deadening myself?
What's the difference between CLD, CCF and MLV?
Do you offer trade or bulk discounts?
How fast is delivery?
Can I return products if they're not suitable?
Need Help Choosing the Right Product?
Our sound deadening experts are here to help. Whether you're doing a full van build or a simple door upgrade, we'll recommend the perfect solution for your project.
