Product Overview
This premium mass loaded vinyl (MLV) is a heavy-duty sound insulation solution designed for automotive applications. Weighing 5kg/sq.m, it incorporates an integrated closed-cell foam layer for effective sound absorption and blocking. It is ideal for transforming any car, van or 4x4 into a quiet and luxurious environment.
Applications
Highly recommended for use in various areas, including:
- Cabin floor
- Bulkhead
- Boot floor
- Lining panels, cupboards and doors at home to insulate and block low-frequency noise transfer
Features
- Integrated closed-cell foam layer that decouples the MLV from vehicle panels, effectively blocking road, engine and exhaust noise.
- Significant reduction in sound transmission, ensuring a quieter driving experience.
- Designed to work optimally on vehicle panels that have been pre-treated with sound deadening mats.
- Flammability tested for vehicle interiors, compliant with ISO 3795:1989 standards.
- High density yet flexible, allowing for easy installation and adaptation to various surfaces.
Dimensions & Specifications
| Specification | Measurement |
|---|---|
| Sheet Size | 600 x 900mm (0.54sq.m / 5.81 sq. feet) |
| Thickness | 8mm |
| MLV Density | 5kg/sq.m |
| Total Weight per Sheet | 2.8kg |
| MLV Temperature Threshold | 90°C continuous / 120°C short |
| CCF Temperature Range | -200°C to +116°C |
Note: Installation may require vinyl adhesive or taped edges. It is recommended to use appropriate tape for securing joints and edges.
Frequently Asked Questions
- What is the best way to install this product? It is recommended to prepare the vehicle panels with sound deadening mats for optimal performance.
- Can this product be used in home applications? Yes, it can be used to insulate and block low-frequency noise in panels, cupboards and doors at home.
- Is this product safe for vehicle interiors? Yes, it has been flammability tested for vehicle interiors according to ISO 3795:1989 standards.
£9.99 Flat UK Shipping
Dispatched within 1-2 working days
Quality Products
Carefully selected products
Expert Support
Call +44 1282 270214
Easy Returns
14-day returns, open and inspect first
| Product Type | MLV Mass Loaded Vinyl |
| SKU | D_SPS05 |
| Weight | Contact for details |
| Availability | ✓ In Stock |
Before You Start
- Clean the surface with isopropyl alcohol or degreaser
- Ensure the surface is completely dry
- Work at room temperature (15°C+) for best adhesion
- Have a roller and utility knife ready
Application Steps
- Step 1: Measure and cut the material to size
- Step 2: Peel back the release paper
- Step 3: Press firmly onto the clean surface
- Step 4: Use a roller to eliminate air bubbles and ensure full contact
- Step 5: For CLD mats, overlap edges slightly for complete coverage
Pro Tips
- For CLD mats: 60-80% coverage gives 95% of the benefit
- Focus on the centre of large flat panels
- Apply CLD first, then CCF/MLV, then acoustic foam
- Use a heat gun in cold conditions to improve adhesion
Shipping
- £9.99 flat-rate shipping on all UK orders
- Dispatched within 1-2 working days (order before 2pm, Mon-Fri)
- 3-6 working days tracked delivery
- Full tracking provided via email
Returns
- 14-day returns on any order, for any reason
- You can open and inspect before you decide
- Contact us before returning: sales@soundproofingshop.co.uk
- Refunds processed within 5 working days
For damaged or faulty items, contact us immediately — we'll arrange a free replacement or full refund.
Frequently Asked Questions
Everything you need to know about sound deadening
How much sound deadening material do I need?
Coverage depends on your vehicle and goals. For basic noise reduction, cover 25-40% of each panel. For maximum results (audio builds, full insulation), aim for 60-80% coverage. Our team can advise on exact quantities for your vehicle — just get in touch.
Can I install sound deadening myself?
Absolutely. All our products are designed for DIY installation with peel-and-stick application. You'll need basic tools — a roller, utility knife, and clean surface. Most door panels take 30-60 minutes. We include installation tips with every order.
What's the difference between CLD, CCF and MLV?
CLD (Constrained Layer Damping) mats reduce vibration and panel resonance — the foundation layer. CCF (Closed Cell Foam) blocks airborne noise and adds thermal insulation. MLV (Mass Loaded Vinyl) is a dense barrier that blocks sound transmission. For best results, use all three in layers.
Do you offer trade or bulk discounts?
Yes! We offer competitive pricing for trade customers, van conversion businesses, and bulk buyers. Contact us with your requirements for a custom quote. Bundle deals are also available on our website.
How fast is delivery?
Orders placed before 2pm are dispatched within 1-2 working days. Once dispatched, transit typically takes a further 2-4 working days. Total delivery time is usually 3-6 working days from when you place your order. Delivery is a flat £9.99 to any UK address. We ship nationwide across the UK.
Can I return products if they're not suitable?
Yes, we offer a 14-day return policy on any order, for any reason, and you may open and inspect it first. Please contact our team to arrange a return. Return postage is yours unless the item is faulty. Items cut to your specification are non-returnable unless faulty.
