Product Overview

This unique product offers two essential layers in one simple application. With soundproofing and insulation combined, this mat will kill vibrations, block noise, and insulate the panels. Simply peel and stick onto the metalwork for an easy application.

Sound Deadening Layer

This mat features a 1.5mm butyl rubber deadening layer that effectively reduces vibration from the panel and acts as a barrier to airborne noise. More rubber and less mineral filler means better vibration damping and noise reduction. Placing this mat on the metal panels of any vehicle will significantly reduce unwanted vibrations and structural noise.

Insulation Layer

The product includes an integral 3mm closed-cell foam insulation layer with excellent thermal and acoustic properties. This layer is ideal for reducing noise and insulating the vehicle, helping to stabilise cabin temperatures throughout the year and reducing the chances of condensation forming.

Convenience

To increase installation convenience, the product is supplied in one continuous 5m sheet (rolled), perfect for custom work and larger areas.

Key Features

• Makes metal panels as dead as possible
• Combines vibration damping, soundproofing, and insulation
• 4.5mm thick with strong adhesive
• Aluminium and pure butyl construction with 1.5mm deadening
• Closed-cell thermo-acoustic 3mm foam insulation
• Soft and flexible; does not require heating
• Stops rattles, vibration, heat, and noise
• Reduces road, exhaust, engine, and transmission noise
• Heat resistant from -50°C to +150°C
• Fully water- and oil-resistant
• Very flexible for easy installation
• Flammability tested for vehicle interiors to ISO 3795:1989
• Peel-and-stick application
• Supplied as a 50cm x 500cm roll
• Coverage of 2.5 sq.m (26.9 sq.ft)

Typical Uses of this Product

• Use on vehicle floors, doors, wheel arches, and side panels
• Low-profile load area underlay for van and camper conversions
• Classic car or 4x4 panels where a smooth plain black finish is preferred
