Product Overview
Most popular vans in the UK start life with very little luxury; however, the load area can be improved dramatically with the application of sound deadening and insulation. Whether your van is a workhorse or a weekend getaway vehicle, this kit offers a simple solution to enhance your van's comfort.
Kit Contents
- 1 x premium hex-embossed sound deadening mat, 50 sheet bulk pack (4.7sq.m)
- 2 x premium 6mm insulation liner, 3m roll (6sq.m)
Installation Details
This pack contains enough sound deadening and sheets of insulation to treat the crucial sides, wheel arch, and roof areas of a small van, including models like:
- Volkswagen Caddy
- Fiat Doblo
- Ford Transit Connect
- Peugeot Partner
- Citroen Berlingo
- Vauxhall Partner
- Renault Kangoo
The hex-embossed sound deadening mat is applied first at approximately a 50% coverage ratio to all single-skin steel areas, such as the side panels, roof, wheel arches, and doors. This is a simple peel & stick application, requiring approximately one bulk 50 sheet (4.7sq.m) pack of sound deadening for these areas.
To complete the installation, add a secondary layer of premium insulation liner to the sides and roof. This product will help regulate the temperatures inside the van, keeping it cooler in summer and warmer in winter. The dense closed-cell foam layer will also work in harmony with the sound deadening layer to improve soundproofing even further.
The final result will be a quieter van with improved ride quality and significantly upgraded interior comfort.
Technical Specifications
- High-Grade Butyl Construction
- Hex Embossed Design
- Aluminium Silver Finish
- Very Soft & Flexible for Easy Installation
- Thickness: 1.8mm with Strong Adhesive
- Noise Reduction: Lowers Road, Exhaust, Engine & Transmission Noise
- Heat Resistant from -40°C to +120°C
- Flammability Tested for Vehicle Interiors ISO 3795:1989
- Fully Water & Oil Resistant
- Peel & Stick Application
- Pack Weight: 14.5kg
- Individual Sheet Size: 370 x 250mm
- Bulk Pack: 50 Sheets
- Pack Coverage: 4.7sq.m (50sq.ft)
Insulation Liner Specifications
- Latest 2023 "v3" Specification
- Efficient Low-Profile 6mm Insulation
- Easy Installation: Cut, Peel & Stick
- High Thermal Efficiency Nitrile Foam
- Significant Noise Reduction
- Warmer in Winter, Cooler in Summer
- Reduces Condensation
- Acts as a Barrier Against Heat
FAQ
Q: Can this kit be installed by a DIY enthusiast?A: Yes, the products are easy to apply and can be cut or shaped with a sharp knife, making them suitable for DIY enthusiasts.
Q: Will this product improve thermal regulation inside my van?A: Yes, the insulation liner helps to regulate temperatures, providing a more comfortable environment inside the van.
Q: Is the sound deadening material resistant to moisture?A: Yes, the sound deadening material is fully water and oil resistant, ensuring durability and effectiveness.
£9.99 Flat UK Shipping
Dispatched within 1-2 working days
Quality Products
Carefully selected products
Expert Support
Call +44 1282 270214
Easy Returns
14-day returns, open and inspect first
| Product Type | Product Bundle |
| SKU | D_SPS75 |
| Weight | Contact for details |
| Availability | ✓ In Stock |
Before You Start
- Clean the surface with isopropyl alcohol or degreaser
- Ensure the surface is completely dry
- Work at room temperature (15°C+) for best adhesion
- Have a roller and utility knife ready
Application Steps
- Step 1: Measure and cut the material to size
- Step 2: Peel back the release paper
- Step 3: Press firmly onto the clean surface
- Step 4: Use a roller to eliminate air bubbles and ensure full contact
- Step 5: For CLD mats, overlap edges slightly for complete coverage
Pro Tips
- For CLD mats: 60-80% coverage gives 95% of the benefit
- Focus on the centre of large flat panels
- Apply CLD first, then CCF/MLV, then acoustic foam
- Use a heat gun in cold conditions to improve adhesion
Shipping
- £9.99 flat-rate shipping on all UK orders
- Dispatched within 1-2 working days (order before 2pm, Mon-Fri)
- 3-6 working days tracked delivery
- Full tracking provided via email
Returns
- 14-day returns on any order, for any reason
- You can open and inspect before you decide
- Contact us before returning: sales@soundproofingshop.co.uk
- Refunds processed within 5 working days
For damaged or faulty items, contact us immediately — we'll arrange a free replacement or full refund.
