Product Overview
This premium product offers two essential layers in one simple application. Designed as a thicker flooring underlay, this high-performance soundproofing and insulation mat features a heavier deadening layer and a thicker insulation layer, making it ideal for vehicle floor and boot areas.
This twin pack covers 5 square metres for comprehensive floor coverage, effectively killing vibrations, blocking noise, and insulating the panels. The easy peel-and-stick application allows for a hassle-free installation onto the metalwork.
Sound Deadening Layer
The sound deadening layer is made from 2mm butyl rubber, designed to reduce vibration from the panel and act as a barrier to airborne noise. The composition, with more rubber and less mineral filler, enhances vibration damping and noise reduction significantly. Placing this on the metal floor of any vehicle will effectively eliminate unwanted vibrations and structural noise.
Insulation Layer
Featuring a 5mm closed-cell foam insulation layer, this mat has excellent thermal and acoustic properties. It effectively reduces noise and insulates the vehicle, helping to stabilise cabin temperatures throughout the year and minimise condensation formation.
Convenience
The product is supplied in one continuous 5m sheet (rolled), perfect for custom work and large floor areas. This design enhances installation convenience, making it suitable for various applications.
- Makes metal panels as dead as can be.
- Professional vehicle floor underlay treatment
- Vibration damping, soundproofing, and insulation combined
- 7mm thick with strong adhesive
- Aluminium and pure butyl construction with 2mm deadening
- Closed-cell thermo-acoustic 5mm foam insulation
- Soft and flexible; does not require heating
- Stops rattles, vibrations, heat, and noise
- Lowers road, exhaust, engine, and transmission noise
- Heat resistant from -50°C to +150°C
- Fully water- and oil-resistant
- Very flexible for easy installation
- Flammability tested for vehicle interiors (ISO 3795:1989)
- Peel-and-stick application
- Supplied as two 50cm x 500cm rolls
- Coverage of 5 square metres (53.8 sq.ft)
Typical Uses
- Superb load area underlay for van or camper conversions.
- Ideal for lowering road, transmission, and exhaust noise in the front footwell, floor, and boot areas of any vehicle.
Technical Specifications
| Specification | Measurement |
|---|---|
| Deadening Layer Thickness | 2mm |
| Insulation Layer Thickness | 5mm |
| Total Thickness | 7mm |
| Coverage | 5 square metres (53.8 sq.ft) |
| Temperature Resistance | -50°C to +150°C |
Frequently Asked Questions
1. How is the mat applied?
The mat is applied using a peel-and-stick method, making it easy to install on metal surfaces.
2. What areas can this mat be used in?
This mat is ideal for vehicle floor and boot areas, as well as for van and camper conversions.
3. Does the mat help with temperature control?
Yes, the closed-cell foam insulation layer helps stabilise cabin temperatures and reduce condensation.
£9.99 Flat UK Shipping
Dispatched within 1-2 working days
Quality Products
Carefully selected products
Expert Support
Call +44 1282 270214
Easy Returns
14-day returns, open and inspect first
| Product Type | CLD Deadening Mat |
| SKU | D_SPS91 |
| Weight | Contact for details |
| Availability | ✓ In Stock |
Before You Start
- Clean the surface with isopropyl alcohol or degreaser
- Ensure the surface is completely dry
- Work at room temperature (15°C+) for best adhesion
- Have a roller and utility knife ready
Application Steps
- Step 1: Measure and cut the material to size
- Step 2: Peel back the release paper
- Step 3: Press firmly onto the clean surface
- Step 4: Use a roller to eliminate air bubbles and ensure full contact
- Step 5: For CLD mats, overlap edges slightly for complete coverage
Pro Tips
- For CLD mats: 60-80% coverage gives 95% of the benefit
- Focus on the centre of large flat panels
- Apply CLD first, then CCF/MLV, then acoustic foam
- Use a heat gun in cold conditions to improve adhesion
