Product Overview

Most popular vans in the UK start life with very little luxury; however, the load area can be improved dramatically with the application of sound deadening and insulation. Whether your van is a workhorse or a weekend getaway vehicle, this kit offers a simple solution to upgrade your van's interior comfort.

Kit Contents

• 2 x hex-embossed sound deadening bulk packs, 50 sheets each (9.4sq.m)
• 1 x 6mm insulation liner, 10m roll (10sq.m)

Installation Instructions

The sound deadening mat is applied first at an approximate 50% coverage ratio to all single-skin steel areas, including side panels, roof, wheel arches, and doors. This is a straightforward peel & stick application. A typical medium-sized van will require approximately two bulk 50 sheet packs (9.4sq.m) for these areas.

To complete the installation, add a secondary layer of insulation liner to the sides and roof. This product helps regulate temperatures inside the van, keeping it cooler in summer and warmer in winter. The dense closed-cell foam layer works in harmony with the sound deadening layer to improve soundproofing even further.

Features & Benefits

• Improves ride quality and significantly upgrades interior comfort.
• All products are easy to apply, self-adhesive, and can be cut or shaped with a sharp knife.
• Designed specifically for automotive use and fire safety tested to ISO 3795.
• Products will not absorb moisture or mould.

Technical Specifications

Sound Deadening Mat Specifications

• Deadens van panels to stop resonance
• High-grade butyl construction
• Hex-embossed with an aluminium silver finish
• Very soft and flexible for easy installation
• Thickness: 1.8mm with strong adhesive
• Stops rattles, vibration, and noise
• Reduces road, exhaust, engine, and transmission noise
• Heat resistant from -40°C to +120°C
• Fully water and oil resistant
• Peel & stick application
• Pack weight: 14.5kg
• Individual sheet size: 370 x 250mm
• Pack coverage: 4.7sq.m (50sq.ft)

Insulation Liner Specifications

• Latest 2023 "v3" specification
• Efficient low-profile 6mm insulation
• Easy installation: cut, peel & stick
• High thermal efficiency nitrile foam
• Significant noise reduction
• Warmer in winter, cooler in summer
• Reduces condensation
• Acts as a barrier against heat loss

Dimensions & Specifications

FAQs

• Q: How do I apply the sound deadening material?
  A: Simply peel off the backing and stick the material to the desired area. It's that easy!
• Q: Is the insulation material effective in extreme temperatures?
  A: Yes, it is heat resistant from -40°C to +120°C, making it suitable for various climates.
• Q: Can I cut the materials to fit specific areas?
  A: Absolutely! The products can be easily cut or shaped with a sharp knife for a perfect fit.
